Ayra Compar Kit FX1 - 22 CH Mode DMX Channels; Derby and Strobe LED DMX

CH Function Value
1 LED main dimmer(Derby) 000 - 255: 0 - 100% intensity
2 Stroboscope speed (Derby) 000 - 007: No function
008 - 249: Stroboscope speed (slow -
fast)
250 - 255: Stroboscope speed (sound-
controlled)
3 Dimmer red (Derby) 000 - 255: Dimmer red, 0 - 100%
intensity
4 Dimmer green (Derby) 000 - 255: Dimmer green, 0 - 100%
intensity
5 Dimmer blue (Derby) 000 - 255: Dimmer blue, 0 - 100%
intensity
6 Dimmer white (Derby) 000 - 255: Dimmer white, 0 - 100%
intensity
7 Colour selection (Derby) 000 - 005: No function
006 - 125: Fixed colours (various
colours)
126 - 189: Colour jumps (slow - fast)
190 - 253: Colour fades (slow - fast)
254 - 255: Colour selection via sound-
controlled mode
8 Derby rotation 000 - 127: Positions
128 - 249: Automatic rotation (slow -
fast)
250 - 255: Sound-controlled movement
9 LED main dimmer (Strobe LEDs) 000 - 255: 0 - 100% intensity
10 Stroboscope speed (Strobe LEDs) 000 - 005: No function
006 - 249: Stroboscope speed (slow -
fast)
250 - 255: Stroboscope speed music-
controlled
11 Show selection Strobe LEDs 000 - 010: No function
011 - 020: Show 1
021 - 030: Show 2
031 - 040: Show 3
041 - 050: Show 4
051 - 060: Show 5
061 - 070: Show 6
071 - 080: Show 7
081 - 240: No function
241 - 255: Random effect
12 Effect speed 000 - 249: Speed (slow - fast)
250 - 255: Sound-controlled function
13 Laser on/off (red) 000 - 010: Red laser off
011 - 020: Red laser on
021 - 255: Stroboscope speed (slow -
fast)
14 Laser on/off (green) 000 - 010: Green laser off
011 - 020: Green laser on
021 - 255: Stroboscope speed (slow -
fast)
15 Laser movement 000 - 099: Laser movement speed (fast
- slow)
100 - 109: No laser movement
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:30-04-2018 RV Revision date and author's initials: -
