Be aware that when you attempt to connect devices of different types and brands, they may behave
strangely and you may not get the desired effect because certain functions are linked to the wrong channels.
This is true of DMX lighting of all brands and types.
DMX
DMX mode is the most comprehensive way to maintain ultimate control over all the functions this device has
to offer. It enables you to determine exactly how many functions you want to control via the DMX controller or
DMX software.
This device can be set to various channel modes so the channel layout, which is shown below, corresponds
perfectly with your DMX circuit layout, as well as with the functions you will be using.
3CH mode:
CH Function Value
1 Show mode 000 - 005: Dimmer out
006 - 055 Random show
056 - 105: Laser show
106 - 155: Derby + strobe show
156 - 205: Par + strobe show
206 - 255: All show
2 If CH1 is set to 056 - 105
Laser show
If CH1 is set to 106 - 155
Derby + Strobe show
If CH1 is set to 156 - 205
Par + Strobe show
If CH1 is set to 206 - 255
All show
000 - 038: Show 1
039 - 101: Show 2
102 - 165: Show 3
166 - 229: Show 4
230 - 255: Show 5
000 - 030: Show 1
031 - 081: Show 2
082 - 132: Show 3
133 - 183: Show 4
184 - 234: Show 5
235 - 255: Show 6
000 - 016: Show 1
017 - 045: Show 2
046 - 073: Show 3
074 - 101: Show 4
102 - 130: Show 5
131 - 158: Show 6
159 - 186: Show 7
187 - 215: Show 8
216 - 243: Show 9
243 - 255: Show 10
000 - 038: Show 1
039 - 101: Show 2
102 - 165: Show 3
166 - 229: Show 4
230 - 255: Show 5
3 Speed selection + sound-controlled mode 000 - 249: Speed (slow - fast)
250 - 255: Sound-controlled
22CH mode:
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:30-04-2018 RV Revision date and author's initials: -
