Guidelines and operation of this device
1. Foot controller - Strobe button
2. Foot controller - Auto button
3. Foot controller - Sound button
4. Foot controller - Blackout button
5. Effect B 2x 10 W RGBW LED Derby light effect
6. Effect A 2x 10 W RGBW LED Derby light effect
7. Red + green grating laser 150 mW
8. 3 W Stroboscope LED
9. flexible gooseneck, hand adjustable
10. LED projector, 12x RGBW 3 W LEDs
11. Effect A lockable connector (5-pin GX-16D connector)
12. C14 power input with fuse holder (100 - 240V AC, 50/60 Hz)
13. C13 link power output (9A maximum)
14. 3-pin XLR input and output for DMX
15. lockable foot controller connector (5-pin GX-16D connector)
16. microphone for sound-controlled operation
17. lockable laser connector (5-pin GX-16D connector)
18. lock for laser (2 keys included)
19. 4-character LED display with menu buttons
20. Effect B lockable connector (5-pin GX-16D connector)
The information in this user manual is subject to change at any time without notice.
