Specifications
Contents:
- basic light bar with electronics and four LED spotlights with goosenecks + 4 stroboscope LEDs
- light stand + bag
- carrying bag
- 2x Derby LED light effect
- 1x RG grating laser
- bag for transport and storage
Light bar properties:
- four spotlights with manually-adjustable goosenecks (movable and rotatable)
- four-character LED display with menu buttons for general control
- infrared receiver on the front
- equipped with a built-in microphone for sound-controlled mode
- mounting points for 3 separate light effects (2X derby, 1x laser)
- connection points for 3 separate light effects, foot controller, power, DMX signal and power output
Remote control
- battery type: CR2025
Light sources:
- spotlights: 12x 1 W R/G/B/W LEDs
- stroboscope LEDs: 4x 1 W white LED
- derby LED light effect: 2x 8 W RGBW *2x
- laser: 150 mW RG laser diodes (100 mW red, 50 mW green)
Laser light effect properties:
Class: 3R laser product
Green:
wavelength: 532 nm
CW/Pulsed: pulsed
max. peak power output (after optics): 3.80 mW
nominal max. output laser diode inside housing : 50 mW
Red:
wavelength: 659 nm
CW/Pulsed: pulsed
max. peak power output (after optics): 1.50 mW
nominal max. output laser diode inside housing: 100 mW
divergence laserdiodes:
- red laserdiode: 1.5 mrad
- green laserdiode: 1.5 mrad
Operating modes:
- stand-alone (programs with adjustable speed or music-controlled)
- master/slave with multiple units linked together
- operation via an external DMX light table (3, 22 or 51 channels)
- operation via an infrared remote control (included)
- operation via a cabled foot controller (included)
- operation via the 4-character LED display and menu buttons on the bar itself
Technical information:
- maximum stand height: approx. 2.1 m
- power supply: 100 - 240V AC, 50/60 Hz
- power consumption: maximum 126 W
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:30-04-2018 RV Revision date and author's initials: -
