Chapter 6. Specifications
z
Harness with dedicated connector 81446594-ITEM
z
81446957-001 AC adapter
Note The 81446594-030 AC adapter connection harness is necessary when supplying AC
power to the CMS.
z
81446594-030 AC adapter connection harness
ITEM: 005, 006
ITEM: 007, 008
81446957-001
