User Manual
This page shows Host IP Address and Host MAC Address for each host blocked by the
router.
Host IP Address The IP address that blocked by DoS are displayed here.
Host MAC Address The MAC address that blocked by DoS are displayed here.
To update this page and to show the current blocked host, click Refresh.
Click Clear All to clear all displayed entries. After the table is empty the blocked host will
regain the capability to access Internet.
Click Return to return to the Advanced Security page
Static Routing
A static route is a pre-determined path that network information must travel to reach a
specific host or network. To add or delete a route, work in the area under the Static
Routing page (shown in figure 5-42).
Static Routing
Destination IP Address The Destination IP Address is the address of the network or
host that you want to assign to a static route.
Subnet Mask The Subnet Mask determines which portion of an IP Address is the
network portion, and which portion is the host portion.
Gateway This is the IP Address of the gateway device that allows for contact
between the router and the network or host.
Page 78 of 102
