User Manual
Specifications
General
Standards IEEE 802.3, 802.3u, 802.11b and 802.11g
Protocols
TCP/IP, PPPoE, DHCP, ICMP, NAT, SNTP
Ports
One 10/100M Auto-Negotiation WAN RJ45 port, Four 10/100M Auto-
Negotiation LAN RJ45 ports supporting Auto MDI/MDIX
Cabling Type
10BASE-T
UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100. STP (maximum 100m)
100BASE-TX
UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100. STP (maximum 100m)
Radio Data Rate 54/48/36/24/18/12/9/6Mbps or 11/5.5/3/2/1Mbp
Power Supply 9V~ 0.8A
LEDs Power, SYS, WLAN, WAN, 1-4
Safety & Emissions FCC, CE
Environmental and Physical
Operating Temp. 0 °C~40 °C (32 °F~104 °F )
Operating Humidity 10% - 95% RH, Non-condensing
Dimensions (W×D×H) 7.3×5.7×1.7 in. (186×146×44 mm) (without antenna)
Page 8 of 102
