Bacharach HI FLOW Sampler User Manual

Operation Hi Flow Sampler
Instruction 0055-9017
34
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
L e a k ( % ) 0 . 0 0
L e a k ( N o t A v a i l . )
S p e e d ( L O < > H I )
S a v e
S t a r t
[ 0 0 0 1 ] ( A ) S - -
5. The user is now asked to choose a new or different Test ID.
Selecting Yes causes the Access Records menu to appear (refer to
Section 3.15). After selecting or creating a new Test ID, start the
measurement by pressing ESC until the Main Screen appears.
Selecting No returns the display to the Main Screen and starts the
measurement using the current Test ID.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
A s s i g n n e w t e s t I D ?
Y e s
N o
[ 0 0 0 1 ] ( A ) S - -
6. (Optional) The instrument normally controls the flow rate for
measurements #1 and #2; however, the user can manually set the
flow rate using the Speed function. Each press of the I/O key will
lower the flow rate as indicated by the speed bar moving to the left.
1 1 / 2 2 / 0 4 0 9 : 4 5 : 3 0
F l o w ( l p m ) 0 . 0
B a c k ( % ) 0 . 0 0
L e a k ( % ) 0 . 0 0
L e a k ( l p m ) 0 . 0
S p e e d ( L O < > H I )
[ 0 0 0 1 ] ( A ) - 1 -
Speed B
ar
