Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 01

STEP 1
BOLT WH
5/16x2 1/4 SD
(5)
BOLT WH
5/16x2 SD
(1)
LAG SCREW
WH 5/16x2 SD
(2)
T-NUT 5/16
SD
(13)
WASHER
LOCK EXT
8x19 SD
(15)
BOLT WH
5/16x3 3/4 SD
(7)
WASHER LOCK EXT 8x19 SD
(6 PLCS)
BOLT WH 5/16x2 1/4 SD
(3 PLCS)
BOLT WH 5/16x3 3/4 SD
(3 PLCS)
T-NUT 5/16 SD
(6 PLCS)
T-NUT 5/16 SD
(1 PLC)
LAG SCREW WH 5/16x2 SD
(2 PLCS)
WASHER LOCK EXT 8x19 SD
(3 PLCS)
T-NUT 5/16 SD
(6 PLCS)
WASHER LOCK EXT 8x19 SD
(6 PLCS)
BOLT WH 5/16x3 3/4 SD
(4 PLCS)
BOLT WH 5/16x2 1/4 SD
(2 PLCS)
BOLT WH 5/16x2 SD
(1 PLC)
B6
M2
H5
E5
G1
B4
H7
B4 - POST - W4L11179
3"
x3"x70 3/8" (76x76x1786)
(1)
B6 - POST - W2A02493
3"x3"x59" (76x76x1500)
(1)
M2 - WALL RAIL - W4L09088
5/8"x3 3/8"x90 1/8" (16x86x2288)
(1)
G1 - GROUND BOARD - W4L09084
1"x5 1/4"x90 1/8" (24x134x2288)
(1)
H7 - FLOOR SUPPORT - W4L09069
1"x3 3/8"x53 3/4" (24x86x1366)
(1)
H5 - FLOOR SUPPORT - W4L09073
1"x3 3/8"x53 3/4" (24x86x1366)
(1)
E5 - UPRIGHT - W4L11182
1
3/8"x3 3/8"x70 3/8" (36x86x1786)
(1)
NOTE HOLES
30
22
