Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 71

STEP 71
T-NUT 5/16
SD
(3)
BOLT WH
5/16x1 1/4 SD
(3)
8 5/8"
1/2"
1/2"
T-NUT 5/16 SD
(3 PLCS)
O70
SCREW PFH 8x1 1/8 SD
(4 PLCS)
BOLT WH 5/16x1 1/4 SD
(3 PLCS)
5 1/2"
6 3/8"
O70
10' VF SLIDE
(1)
QU - SLIDE VF 10 FT - A100287 OR 50250
SCREW PFH
8x1 1/8 SD
(4)
O70 - SLIDE MOUNTING BOARD - W4L09040
5/8"x1 3/8"x20 3/8" (16x34x517)
(1)
92
