Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 02

STEP 2
G1 - GROUND BOARD - W4L09084
1"x5 1/4"x90 1/8" (24x134x2288)
(1)
H5 - FLOOR SUPPORT - W4L09073
1"x
3 3/8"x53 3/4" (24x86x1366)
(1)
B5
K1
H5
E4
B3
G1
BOLT WH 5/16x2 1/4 SD
(1 PLC)
WASHER LOCK EXT 8x19 SD
(2 PLCS)
T-NUT 5/16 SD
(2 PLCS)
BOLT WH 5/16x3 3/4 SD
(1 PLC)
T-NUT 5/16 SD
(5 PLCS)
BOLT WH 5/16x3 1/2 SD
(4 PLCS)
WASHER LOCK EXT 8x19 SD
(5 PLCS)
BOLT WH 5/16x2 SD
(1 PLC)
T-NUT 5/16 SD
(6 PLCS)
WASHER LOCK EXT 8x19 SD
(6 PLCS)
BOLT WH 5/16x3 3/4 SD
(4 PLCS)
BOLT WH 5/16x2 1/4 SD
(2 PLCS)
NOTE HOLE
BOLT WH
5/16x3 1/2 SD
(4)
BOLT WH
5/16x2 1/4 SD
(3)
BOLT WH
5/16x2 SD
(1)
T-NUT 5/16
SD
(13)
WASHER
LOCK EXT
8x19 SD
(13)
B3 - POST - W4L11178
3"x
3"x70 3/8" (76x76x1786)
(1)
B5 - POST - W4L11180
3"x3"x59" (76x76x1500)
(1)
E4 - UPRIGHT - W4L11181
1 3
/8"x3 3/8"x70 3/8" (36x86x1786)
(1)
K1 - DOUBLE ARCHED RAIL - W4L09079
5/8
"x5 1/4"x90 1/8" (16x134x2288)
(1)
BOLT WH
5/1
6x3 3/4 SD
(5)
NOTE
HOLES
NOTE HOLE
ORIENTATION
