STEP 67
SCREW PFH
8x1 1/8 SD
(24)
M47 - PICKET - 51 - W4L11233
5/
8"x3 3/8"x25 1/4" (16x86x640)
(6)
3
EQUALLY SPACED
1 13/16"
SCREW PFH 8x1 1/8 SD
(24 PLCS)
M476 PLCS
88
