Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 04

STEP 4
T-NUT 5/16
SD
(6)
BOLT WH
5/16x3 3/4 SD
(4)
LAG SCREW
WH 5/16x2 SD
(6)
WASHER
LOCK EXT
8x19 SD
(12)
M8 - WALL RAIL - W4L09085
5/
8"x3 3/8"x51 3/4" (16x86x1314)
(1)
G3 - GROUND BOARD - W4L09087
1"x5 1/4"x78 1/4" (24x134x1987)
(1)
H2 - FLOOR SUPPORT - W4L09066
1"x3 3/8"x75 3/8" (24x86x1914)
(1)
H8 - FLOOR SUPPORT - W4L09064
1"x3 3/8"x53" (24x86x1346)
(1)
T-NUT 5/16 SD
(4 PLCS)
WASHER LOCK EXT 8x19 SD
(4 PLCS)
BOLT WH 5/16x3 3/4 SD
(4 PLCS)
FLUSH
WASHER LOCK EXT 8x19 SD
(6 PLCS)
LAG SCREW WH 5/16x2 SD
(6 PLCS)
NOTE HOLES
H8
H2
M8
G3
BOLT WH 5/16x1 3/4 SD
(2 PLCS)
WASHER LOCK EXT 8x19 SD
(2 PLCS)
T-NUT 5/16 SD
(2 PLCS)
H21
H21 - ANGLE BRACE - W4L11112
1"x3 3/8"x47 1/4" (24x86x1201)
(1)
BOLT WH
5/
16x1 3/4 SD
(2)
WASHER LOCK EXT 6x15 SD
LAG SCREW WH 1/4x2 SD
LAG SCREW
WH
1/4x2 SD
(1)
WASHER
LOCK EXT
6x15 SD
(1)
33
25
