STEP 36
SCREW PFH
8x1 1/8 SD
(12)
M49 - PICKET - 53 - W4L11234
5/
8"x3 3/8"x20 3/8" (16x86x518)
(3)
2 7/16"
TY
PICAL SPACING
1 13/16"
SCREW PFH 8x1 1/8 SD
(12 PLCS)
M49
3 PLCS
57
