Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 13

STEP 13
T-NUT 5/16
SD
(7)
BOLT WH
5/16x2 1/4 SD
(5)
LAG SCREW
WH 5/16x2 SD
(5)
WASHER
LOCK EXT
8x19 SD
(10)
F5 - BRACE - W4L11187
1 3
/8"x2 3/8"x18 1/8" (36x60x460)
(3)
BOLT WH 5/16x2 1/4 SD
(5 PLCS)
LAG SCREW WH 5/16x2 SD
(5 PLCS)
WASHER LOCK EXT 8x19 SD
(10 PLCS)
F5
3 PLCS
2 PLCS
F6
F6 - BRACE - W4L11632
1 3
/8"x2 3/8"x18 1/8" (36x60x460)
(2)
T-NUT 5/16 SD
(2 PLCS)
INSTALL THESE BEFORE
INSTALLING BRACES.
T-NUT 5/16 SD
(5 PLCS)
INSERT T-NUTS INTO 'F5' & 'F6'
BRACE BEFORE INSTALLING.
