Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 59

STEP 59
WASHER
LOCK EXT
8x19 SD
(4)
LAG SCREW
WH 5/16x3 SD
(4)
SCREW PFH
8x2 SD
(4)
F4 - UPRIGHT - W4L09063
1
3/8"x2 3/8"x23 1/8" (36x60x586)
(2)
3 11/16"
3 11/16"
6 7/8"
13 3/16"
F4
2 PLCS
SCREW PFH 8x2 SD
(4 PLCS)
WASHER LOCK EXT 8x19 SD
(4 PLCS)
LAG SCREW WH 5/16x3 SD
(4 PLCS)
LEAVE LOOSE AT THIS POINT.
PLASTIC TUNNEL TO BE
INSTALLED LATER.
NOTE:
DRILL 3/16" (5 MM) HOLES WHERE INDICATED.
80
