Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 11

STEP 11
WASHER
LOCK EXT
12x19 SD
(6)
NUT BARREL
WH 5/16x7/8
SD
(6)
BOLT WH
5/16x1/2 SD
(1)
- L BRACKET 2.5x38x50x55 - A100340
(3)
L9 - CORNER BOARD - W4L11215
5/
8"x4 3/8"x31" (16x112x788)
(2)
L6 - CORNER BOARD - W4L11111
5/8"x4 3/8"x31" (16x112x788)
(1)
E1 - FLOOR SUPPORT - W4L09077
1 3/8"x3 3/8"x92" (36x86x2336)
(1)
L8 - CORNER BOARD - W4L11214
5/8"x4 3/8"x31" (16x112x788)
(1)
BOLT WH
5/
16x1 3/4 SD
(2)
BOLT WH
5/16x1 1/4 SD
(2)
BOLT WH
5/16x1 SD
(1)
THIS HOLE
TOWARDS
BOTTOM
NUT BARREL WH 5/16x7/8 SD
(2 PLCS)
WASHER LOCK EXT 12x19 SD
(2 PLCS)
BOLT WH 5/16x1 1/4 SD
(1 PLC)
BOLT WH 5/16x1 3/4 SD
(1 PLC)
L BRACKET 2.5x38x50x55
(3 PLCS)
BOLT WH 5/16x1/2 SD
(1 PLC)
BOLT WH 5/16x1 SD
(1 PLC)
WASHER LOCK EXT 12x19 SD
(2 PLCS)
NUT BARREL WH 5/16x7/8 SD
(2 PLCS)
NUT BARREL WH 5/16x7/8 SD
(2 PLCS)
WASHER LOCK EXT 12x19 SD
(2 PLCS)
BOLT WH 5/16x1 1/4 SD
(1 PLC)
BOLT WH 5/16x1 3/4 SD
(1 PLC)
L9
L6
L8
L9
40
32
