Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 03

STEP 3
LAG SCREW
WH 5/16x2 SD
(8)
WASHER
LOCK EXT
8x19 SD
(10)
M8 - WALL RAIL - W4L09085
5/
8"x3 3/8"x51 3/4" (16x86x1314)
(2)
G4 - GROUND BOARD - W4L09086
1"x5 1/4"x78 1/4" (24x134x1987)
(1)
M8
H21
M8
G4
H21 - ANGLE BRACE - W4L11112
1"
x3 3/8"x47 1/4" (24x86x1201)
(1)
FLUSH
WASHER LOCK EXT 8x19 SD
(8 PLCS)
LAG SCREW WH 5/16x2 SD
(8 PLCS)
BOLT WH 5/16x1 3/4 SD
(2 PLCS)
T-NUT 5/16 SD
(2 PLCS)
WASHER LOCK EXT 8x19 SD
(2 PLCS)
LAG SCREW
WH
1/4x2 SD
(1)
BOLT WH
5/16x1 3/4 SD
(2)
T-NUT 5/16
SD
(2)
38 mm
[1
1/2 in]
54 mm
[2 1/8 in]
LAG SCREW WH 1/4x2 SD
(1 PLC)
WASHER LOCK EXT 6x15 SD
(1 PLC)
38 m
m
[1 1/2 in]
WASHER
LOCK EXT
6x15 SD
(1)
32
24
