Backyard Discovery 1801080 - WOODRIDGE ELITE - STEP 54

STEP 54
T-NUT 5/16
SD
(6)
BOLT WH
5/16x2 1/4 SD
(4)
WASHER
LOCK EXT
8x19 SD
(8)
BOLT WH
5/16x3 SD
(2)
E3 - BRACE - W4L09103
1
3/8"x3 3/8"x72 5/8" (36x86x1845)
(2)
G2 - GROUND BOARD - W4L09104
1"x5 1/4"x89 1/2" (24x134x2274)
(1)
E3
E3
G2
BOLT WH 5/16x3 SD
(2 PLCS)
BOLT WH 5/16x2 1/4 SD
(4 PLCS)
WASHER LOCK EXT 8x19 SD
(8 PLCS)
T-NUT 5/16 SD
(6 PLCS)
LAG SCREW WH 5/16x2 1/2 SD
(2 PLCS)
LAG SCREW
WH
5/16x2 1/2
SD
(2)
75
