Meter Setup Menu
Meter Setup
Calibration Diameter
A
This parameter is set at the factory. In the event the amplifier is replaced,
verify that the pipe diameter matches the installed pipe size.
Detector Factor
A
This parameter is set at the factory. This factor compensates for accuracy
error as a result of the installed detector.
In the event the amplifier is replaced, this parameter must be
reprogrammed with the original detector zero.
Detector Zero
A
This parameter is set at the factory.
This parameter compensates for accuracy error as a result of the installed
detector.
In the event the amplifier is replaced, this parameter must be
reprogrammed with the original detector factor.
Amplifier Factor This parameter is set at the factory and is Read Only. This factor
compensates for accuracy error as a result of the installed amplifier.
Coil Current This parameter is set at the factory and is Read Only. This factor
compensates for accuracy error as a result of the installed amplifier.
Scale Factor
S
Changing the scale factor lets you adjust the meter´s accuracy without disturbing parameters set
by the factory. You can tune the meter to meet changing application requirements.
Power Line Frequency
S
This parameter is set at the factory.
This parameter provides measuring immunity to industrial noise from a power supply feed.
Period
A
This parameter configures the frequency (1/4, 1…99 seconds) of sampled measurements. In other
words, if set to 15, then every 15 seconds it will sample for 208 micro seconds.
OTE:N Parameters indicated by the battery icon, if changed will affect battery performance.
Standard sampling period is 15 seconds.
Empty Pipe Detection Empty Pipe ON/OFF
S
When set to ON, an Empty Pipe condition indicates to the outputs
that the meter is not completely filled. When set to OFF, empty pipe
conditions are not detected.
Threshold
S
This parameter is set at the factory and adjusted to the conductivity of
normal water.
Measure Measures the real empty pipe value. This parameter is Read Only.
M-Series® M5000 Electromagnetic Flow Meter
Page 22 September 2013
