Errors & Warnings
What You See
Why It Happened
How to Fix It
MEASURE_TIMEOUT
The board may be damaged. Contact Badger Meter Technical Support.
COMMON_MODE_VOLTAGE_
OVERLOAD
Common mode voltage is smaller than
–2.0V or larger than +4.1V.
Make sure the meter is properly grounded.
Empty detector. Switch Empty Pipe detection ON.
Dirty electrodes. Clean the electrodes.
EMPTY_PIPE_WARNING
Measured impedance between the Empty Pipe
electrode and the Ground exceeded the set value.
• Make sure the pipe is filled.
• Check Empty Pipe threshold. It should be
60000 Ω (corresponds with 20 µS/cm).
Empty detector.
PULSE_OVERLOAD_WARNING
Overow occurred on the ow output. Lower the pulse number.
FLOW_OVERLOAD_WARNING
Flow exceeded the Full Scale of more than 100%. Set the flow range properly.
LOW_POWER_WARNING
Battery voltage is smaller than 3.0V. Consider replacing the battery.
EEPROM_ERROR
Conguration le is missing. Replace the board.
CONFIG_ERROR
Conguration le is corrupted. Replace the board.
PREAMPLIFIER_OVERLOAD
Input voltage exceeded the limits. Maximum polarization is ± 227 mV; maximum
power line noise is 10.6 mV; maximum useful
signal is 10.7 mV.
Empty detector. Switch Empty Pipe detection ON.
Dirty electrodes. Clean the electrodes.
COIL ERROR
Coil/sensor is not connected. • Make sure wiring is properly connected to the
amplifier.
• If that does not clear the alarm, contact
Badger Meter Technical Support.
Coil shorted.
Issue with coil current.
