Operating Manual BaehrTec A1200 / A2000
Page 54/64 English – V100 - Date 09/2017
1.
Turn off the device at the main switch and disconnect it from the power supply.
Never clean the device while the handpiece motor is still running! Risk of injury!
In addition, the clamping mechanism will suffer damage!
2. Put on a disposable glove, or pull a finger cot over the thumb on the hand with which
you want to hold the handpiece while cleaning, and then hold the handpiece in this hand.
3. Now press on the top of the handpiece with your thumb. By holding the tip with the
disposable glove/finger cot, you prevent the tip from turning while cleaning (see Fig. 36).
4. Insert the clamping mechanism cleaner 1 without pressure as far as possible into the
opening of your handpiece and turn the clamping mechanism cleaner 1, pressing slightly
to the left and right (see Fig. 37).
5. Now pull out the clamping mechanism cleaner 1 from the opening. Next, remove the dirt
from the grooves on the clamping mechanism cleaner 1 with a small brush. Repeat the
cleaning process until you cannot remove any more dirt.
6. After use, clean the clamping mechanism cleaner 1 with Baehr quick surface
disinfectant (Art-No. 11015).
7. Now remove any final impurities with the clamping mechanism cleaner 2 by inserting it
as deep as possible into the opening on your handpiece and then turning to the left and
right (see Fig. 38).
8. Now pull out the clamping mechanism cleaner 2 from the opening.
9. Only clean the clamping mechanism cleaner 2 with water, then with Baehr quick surface
disinfectant (Art-No. 11015) and then with Baehr Alcohol (Art-No. 11032) to degrease
the tool.
Fig. 36 Fig. 37 Fig. 38
You can also clean Easy-Clean in the event that cream, fat, oil or the like gets into the
clamping mechanism.
