11
MANUAL DOOR & LOCKS
• All 4 doors can be opened from inside/outside by pulling the door latch as shown in Figure: a.
• All the doors can also be locked or unlocked independently from inside by rotating the knob in
anticlockwise and clockwise as shown in Figure: c and d.
• To lock/unlock driver side door, insert the key and rotate it clockwise or anticlockwise respectively for LHD
vehicles.
• To lock/unlock driver side door, insert the key and rotate it anticlockwise or clockwise respectively for
RHD vehicles.
Warning:
- Ensure rotary knobs are in position during vehicle running.
- During vehicle movement, Passengers(especially children) can accidently open the doors which can
be dangerous. hence it is suggested that all passengers wear seat belts properly & also ensure door is
locked while vehicle is driven.
a
b
cc
d
2A-1. MAIN DOORS:
*Accessories shown may not be a part of standard fitment.
