24
2H. Cylinder & Refueling (LPG):
a. LPG Cylinder:
It is mounted below driver seat.
b. Multifunction Valve :
It is mounted on LPG cylinder. It is an assembly, mounted on LPG tank for filling tank &
withdrawal of LPG along with safety devices.
c. Manual Shut off Valve :
This shut off valve is to be closed when vehicle is parked for longtime or overnight. Also in case
of any leakage observed this valve is to be closed immediately. To close shut off valve, rorate
the nut clockwise.
d. Content Gauge (gas quantity indicator) :
This is used to covert content gauge signal to the dashboard for fuel level indicator.
d
a
b
c
