2I. Cylinder & Refueling (CNG):
Refueling:
Refueling is done via CNG filler valve A Dust cap is provided in this unit. Refueling should be
done when CNG symbol blinks at the instrument cluster. To refill the cylinder with CNG gas,
open the lockable door provided at RH side of body as shown in Fig. Remove Dust cap & fill the
gas into cylinder till the pressure in cylinder reached 200 bar. Close the refueling unit by
inserting Dust cap.
Caution:
Ensure that Dust cap is fitted properly in refueling unit. The vehicle will not start if Dust cap is
loosely fitted.
d
Dust cap
Filling valve
