PanaFlow™ XMT1000 User’s Manual 73
Chapter 4. Error Codes and Troubleshooting
4.9 Option I/O Errors
X15: Font API Initialize Fail Failed to generate font Failed to generate font. Try power cycling the meter.
If error persists after power cycle, contact
Panametrics factory
X16: XML File Initialize Fail XML file initialization failed XML file initialization failed. Try power cycling the
meter. If error persists after power cycle, contact
Panametrics factory
X17: Disconnect Std Dout Transmitter Error Fault: Transmitter Error. Connect the digital input to
meter. If error persists , contact Panametrics factory
X18: Aout(Std) Out Of
Range
Transmitter Out Of Range Error Fault: Transmitter Out Of Range Error, Configure
analog out with in the range, If error persists,
contact Panametrics factory
Table 27: Option I/O Errors Description
Error Code Error Message Description
A1:AnalogCh(S2:3) Error! ADC Channel(S2:3) is not
responding
Analog input /RTD input is not working. If error
persists after power cycle, contact Panametrics
factory
A2:AnalogCh (S2:4) Error! ADC Channel(S2:4) is not
responding
Analog input /RTD is not working. If error persists
after power cycle, contact Panametrics factory
A3:AnalogCh (S2:1) Error! DAQ Channel (S2:1) is not
responding
Analog output (4-20mA) is not working. If error
persists after power cycle, contact Panametrics
factory
A4:AnalogCh (S2:2) Error! DAQ Channel (S2:2) is not
responding
Analog output (4-20mA) is not working. If error
persists after power cycle, contact Panametrics
factory
A6:(S2:3)Ch Not Calibrated Error occurs when Analog
Input/RTD (S2:3) are not
calibrated
Calibrate the Analog Input/RTD input. If error
persists after calibration, contact Panametrics
factory
A7:(S2:4)Ch Not Calibrated Error occurs when Analog
Input/RTD (S2:4) are not
calibrated
Calibrate the Analog Input/RTD input. If error
persists after calibration, contact Panametrics
factory
A8: (S2:1)Ch Not Calibrated Error occurs when Analog
Input/RTD (S2:1) are not
calibrated
Calibrate the Analog Input/RTD input. If error
persists after calibration, contact Panametrics
factory
A9: (S2:2)Ch Not Calibrated Error occurs when Analog
Input/RTD (S2:1) are not
calibrated
Calibrate the Analog Input/RTD input. If error
persists after calibration, contact Panametrics
factory
A10:(S2:3)Input NotConnect! Analog Input: Error occurs when
(4-20mA) input is not
connected at Channel (S2:3).
RTD Input: Error occurs when
RTD input is not connected or
temp greater than 390 deg C at
Channel (S2:3)
Check connectivity for Analog Input/RTD input and
RTD temperature. Try power cycling the meter. If
error persists after power cycle, contact
Panametrics factory
Table 26: Transmitter Error Description and Recommended Actions
Error Code Error Message Description / Recommended Action
