Appendix A. Specifications
80 PanaFlow™ XMT1000 User’s Manual
A.2 Electronics
Enclosures
Powder coated aluminum or stainless steel (SS316)
Classifications
XMT1000 PanaFlow Transmitter
USA/Canada - explosion-proof class I, division 1, groups B, C, and D
ATEX - Flameproof II 2 G Ex db IIC T6 Gb; Ta = -45°C to +65°C
FISCO Ex db [ia Ga] IIC T6 Gb; Ta = -45°C to +60°C
IECEx - Flameproof Ex db IIC T6 Gb; Ta = -45°C to +65°C
FISCO Ex db [ia Ga] IIC T6 Gb; Ta = -45°C to +60°C
PanaFlow PF10 Ultrasonic Liquid Flow Meter
USA/Canada - explosion-proof class I, division 1, groups B, C, and D
ATEX - Flameproof II 2 G Ex db IIB+H2 T6…T3 Gb; Ta = -40°C to +60°C ... +65°C
IECEx - Flameproof Ex db IIB+H2 T6…T3 Gb; Ta = -40°C to +60°C ... +65°C
RoHS compliance (Directive 2011/65/EU)
CE Marking (EMC directive 2014/30/EU, LVD 2014/35/EU, ATEX 2014/34/EU & RoHS 2011/65/EU)
WEEE compliance (Directive 2012/19/EU)
Electronics Mounting
Local or remote mounting Paths Three paths
Display
English
128 x 64 mono-color LCD display, configurable for single or dual measurement parameters
Keypad
Built-in magnetic, six-button, lockable keypad
Standard Inputs/Outputs
One 4 to 20 mA isolated output, 600-ohm maximum load
One additional output, may be configured as either pulse, frequency or alarm.
Additonal Inputs/Outputs
Two 4 to 20 mA isolated output, 600-ohm maximum load
Two 4 to 20 mA isolated input or RTD sensor input (Supports PT100: 3 and 4 Wire, PT1000: 3 and 4 Wire)
One additional 4 to 20 mA isolated output (SIL), 600 Ohm maximum load
Digital Interfaces
Standard: RS485/Modbus® Optional: HART® 7.0 protocol, with 4 dynamic variables, includes one additional 4 to 20 mA
analog output NAMUR NE43
Optional: Foundation Fieldbus® FISCO, LAS capable NAMUR NE107 with 5 AI blocks and a PID block
