4 Technical data
Port
Standard port
Status
Function
off
Status of input or output pin is 0
Yellow
Status of input or output pin is 1
Both LEDs flashing red
Short circuit at sensor supply between pin 1 and pin 3
Red
Short circuit at output at pin 2 / 4 against pin 3
Red
No high signal at diagnostic input
IO-Link port
Status
Function
Green
IO-Link – connection active
Green, flashing
No IO-Link – connection or wrong IO-Link device
Green, fast flashing
IO-Link pre-operate during data management
Red, fast flashing
Validation failed / wrong configuration of IO-Link data length
Red, fast flashing
Data management failed / wrong device for data management
Red
IO-Link short circuit, pin 4 against pin 3
