8 Diagnostics
Channel Number
8.4.
2 bytes of data that describe where the error on the module has occurred.
Slot 1: Configuration as standard I/O ports
Value
Position
0x0000
Port 0 pin 4
0x0001
Port 1 pin 4
0x0002
Port 2 pin 4
0x0003
Port 3 pin 4
0x0004
Port 4 pin 4
0x0005
Port 5 pin 4
0x0006
Port 6 pin 4
0x0007
Port 7 pin 4
0x000A
Port 0 pin 2
0x000B
Port 1 pin 2
0x000C
Port 2 pin 2
0x000D
Port 3 pin 2
0x000E
Port 4 pin 2
0x000F
Port 5 pin 2
0x0010
Port 6 pin 2
0x0011
Port 7 pin 2
0x0020
Error on the module:
Error affects the whole module, not a single port.
(for example undervoltage)
Slot 2-5: Configuration as IO-Link
0x0000
Error on IO-Link port
0x0001
Error on IO-Link device
