6 CC-Link IE Field Basic
General
CC-Link IE Field Basic is an open fieldbus based on Ethernet technology. The Ethernet
technology allows traditional Ethernet cables to be used. CC-Link IE Field Basic is designed
for star topologies only.
A traditional 100Base-T switch is entirely sufficient here.
Due to the switch integrated into the CIB module which enables a star topology, line
topologies can also be realized. This means that you can connect multiple CIB modules
together in a string.
CC-Link IE Field
Basic network
Element
Specification
Maximum number of stations in a
network
64 maximum (One module may occupy multiple stations)
Group
The maximum number of stations in a group is 16.
(To connect more than 16 stations you must use several groups.)
Cyclical data
RY
64 bits (per station) (One module may occupy multiple stations.)
RX
64 bits (per station) (One module may occupy multiple stations.)
RWw
32 words (per station) (One module may occupy multiple stations.)
RWr
32 words (per station) (One module may occupy multiple stations.)
Port numbers
61450 (cyclic data)
61451 (port number of the slave station for NodeSearch and
IPAddressSet)
Ethernet
Element
Specification
Communication speed
100 Mbps
Network topology
Star
Connection cable
Ethernet cable 100Base-T Standard: Category 5e or higher
(double shielded recommended)
Maximum distance between
stations
100m max. (ANSI/TIA/EIA-568-B, Category 5e)
Total cable length
Star: Depends on system configuration
CIB module
Element
Specification
Maximum number of occupied
stations
5
