Balluff BNI00E7 User Manual

Balluff Network Interface CC-Link IE Field Basic
www.balluff.com
2
1 General
Structure of the
guide
This guide is arranged so that one section builds upon the other.
Chapter 2: Basic safety instructions
Chapter 3: First steps
….…
Typographical
conventions
The following typographical conventions are used in this manual.
Enumerations
Enumeration is shown in the form of bulleted lists.
• Entry 1
• Entry 2
Actions
Action instructions are indicated by a preceding triangle. The result of an action is indicated
by an arrow.
➢ Instruction 1
 Result of action
➢ Instruction 2
Actions can also be indicated as numbers in parentheses.
(1) Step 1
(2) Step 2
Syntax
Numbers:
Decimal numerals are shown without an additional indicator (e.g. 123).
Hexadecimal numbers are shown with the additional reference hex or 0x (e.g. 0xA3, C2hex).
Cross-references
Cross-references indicate where additional information about the topic can be found.
Symbols
Note
This symbol indicates general notes.
Attention!
This symbol indicates a safety notice which must be observed.
Abbreviations
BNI Balluff Network Interface
CIB CC-Link IE Field Basic
EMC Electromagnetic Compatibility
FE Function earth
HW Hardware
IOL IO-Link
ISDU IO-Link Parameter (Index Service Data Unit)
N/A Not available
PLC Programmable Logic Controller
SIO Standard in-/outputs
SW Software
UA Actuator supply
US Sensor supply
RWr Word data input as seen from the master station
RWr Word data output as seen from the master station
RX Bit data input as seen from the master station
RX Bit data output as seen from the master station
Deviating views
Product views and illustrations in this guide may differ from the actual product.
They are intended only as illustrative material.

Balluff BNI00E7 Specifications

General

Brand	Balluff
Model	BNI00E7
Category	I/O Systems
Language	English
