7 Cyclical transmission
General
Cyclic data transmission is divided into a bit and a word area.
CC-Link IE Field Basic is based on stations, whereby each station incorporates 64 bits and
32 words.
The BNI CIB module can be configured for between 2 and 5 stations and thereby offers various
process data sizes of 8 to 32 bytes. The bit area is the same for all station configurations. In
addition to the status information, the word area also contains the IO-Link process data, the
size of which varies with the configuration. The process data size applies to both input and
output data. A word is filled with two bytes.
Number of stations
Size of the process data (RWr and RWw)
2
8 bytes in-/out process data per port
3
16 bytes in-/out process data per port
4
24 bytes in-/out process data per port
5
32 bytes in-/out process data per port
RX and RY
Register
Slave Master
Register
Master Slave
RXm00
h
X 0 (Port 0, Pin 4)
RYm00
h
Y 0 (Port 0, Pin 4)
RXm01
h
X 1 (Port 0, Pin 2)
RYm01
h
Y 1 (Port 0, Pin 2)
RXm02
h
X 2 (Port 1, Pin 4)
RYm02
h
Y 2 (Port 1, Pin 4)
RXm03
h
X 3 (Port 1, Pin 2)
RYm03
h
Y 3 (Port 1, Pin 2)
RXm04
h
X 4 (Port 2, Pin 4)
RYm04
h
Y 4 (Port 2, Pin 4)
RXm05
h
X 5 (Port 2, Pin 2)
RYm05
h
Y 5 (Port 2, Pin 2)
RXm06
h
X 6 (Port 3, Pin 4)
RYm06
h
Y 6 (Port 3, Pin 4)
RXm07
h
X 7 (Port 3, Pin 2)
RYm07
h
Y 7 (Port 3, Pin 2)
RXm08
h
X 8 (Port 4, Pin 4)
RYm08
h
Y 8 (Port 4, Pin 4)
RXm09
h
X 9 (Port 4, Pin 2)
RYm09
h
Y 9 (Port 4, Pin 2)
RXm0A
h
X A (Port 5, Pin 4)
RYm0A
h
Y A (Port 5, Pin 4)
RXm0B
h
X B (Port 5, Pin 2)
RYm0B
h
Y B (Port 5, Pin 2)
RXm0C
h
X C (Port 6, Pin 4)
RYm0C
h
Y C (Port 6, Pin 4)
RXm0D
h
X D (Port 6, Pin 2)
RYm0D
h
Y D (Port 6, Pin 2)
RXm0E
h
X E (Port 7, Pin 4)
RYm0E
h
Y E (Port 7, Pin 4)
RXm0F
h
X F (Port 7, Pin 2)
RYm0F
h
Y F (Port 7, Pin 2)
RXm10
h
Diagnostic XY 0
RYm10
h
Direction XY 0
RXm11
h
Diagnostic XY 1
RYm11
h
Direction XY 1
RXm12
h
Diagnostic XY 2
RYm12
h
Direction XY 2
RXm13
h
Diagnostic XY 3
RYm13
h
Direction XY 3
RXm14
h
Diagnostic XY 4
RYm14
h
Direction XY 4
RXm15
h
Diagnostic XY 5
RYm15
h
Direction XY 5
RXm16
h
Diagnostic XY 6
RYm16
h
Direction XY 6
RXm17
h
Diagnostic XY 7
RYm17
h
Direction XY 7
RXm18
h
Diagnostic XY 8
RYm18
h
Direction XY 8
RXm19
h
Diagnostic XY 9
RYm19
h
Direction XY 9
RXm1A
h
Diagnostic XY A
RYm1A
h
Direction XY A
RXm1B
h
Diagnostic XY B
RYm1B
h
Direction XY B
RXm1C
h
Diagnostic XY C
RYm1C
h
Direction XY C
RXm1D
h
Diagnostic XY D
RYm1D
h
Direction XY D
RXm1E
h
Diagnostic XY E
RYm1E
h
Direction XY E
RXm1F
h
Diagnostic XY F
RYm1F
h
Direction XY F
RXm20
h
Diagnostic Port 0
RYm20
h
Display Red LED
RXm21
h
Diagnostic Port 1
RYm21
h
Display Green LED
RXm22
h
Diagnostic Port 2
RYm22
h
Display Locked
m = assigned module station number
