Now select Online ā Parameter Processing of Slave Station. The following window should open:
Use the drop-down menu "Method Selection" to select whether you want to read or write
parameters. Clicking on the "Execute" button either reads or writes all the selected parameters.
Use the checkboxes at the left of each parameter block to select this.
Initial Value: The Initial Value column always shows the initial value, i.e. also the one the
module uses for starting from the factory settings.
Read Value: When parameters have been read the value is shown here. Note: When a
parameter has been written, it will only be the same when reading if the configuration was
applied in the intermediate step using the "Initial Operation Completion" contained in the
process data image.
