Balluff BTL6-A/C/E/G500-M Series User Manual

16 english
9
Resetting all values (reset)
NOTICE!
Interference in function
Resetting the values while the system is running may
result in malfunctions.
► Stop the system before performing the reset.
The reset function can be used to restore all the settings
to the factory settings. For a reset the magnet may also be
located outside the measuring range.
LED display
LED
1. Activate reset
► Simultaneously activate
a
and
b
for at least 4s.
>4s
a
b
2. Reset
► Simultaneously activate
a
and
b
for at least 4s.
>4s
a
b
After activation:
⇒ All values are reset.
⇒ Current position value is displayed.
⇒ Reset is deactivated.
3. Abort reset
Resetting can be aborted without any changes
being saved after the Activate reset step.
► Briefly activate
a
and
b
simultaneously (<1s).
<1s
a
b
⇒ Current position value is displayed.
LED legend: LED green LED flashing green
LED red
BTL6-A/C/E/G500-M _ _ _ _ -PF-S115
Micropulse Transducer in a Flat Profile Housing
