10.1 Accuracy
The specifications are typical values for BTL6-A/C/E/G... at
24VDC and room temperature, with a nominal length of
500mm in conjunction with the BTL5-P-3800-2,
BTL5-P-4500-1, BTL5-P-5500-2, BTL6-A-3800-2,
BTL6-A-3801-2, BTL5-F-2814-1S or BTL5-T-2814-1S
magnet.
The transducer is fully operational immediately, with full
accuracy after warm-up.
For special versions, other technical data may
apply.
Special versions are indicated by the suffix -SA
on the part label.
Resolution
BTL6-A/G... 350µV
≥5µm
BTL6-C/E... 700nA
≥5µm
Repeat accuracy ≤±0.002% FS
≥±5µm
Sampling rate
(dependent on the nominal length)
Max.2kHz
Non-linearity at
Nominal length≤500mm
Nominal length>500mm
±200µm
±0.04%FS
Temperature coefficient
1)
≤30ppm/K
Max. detectable speed 10m/s
10.2 Ambient conditions
2)
Operating temperature −25°C…+70°C
Storage temperature −40°C…+100°C
Relative humidity <90%, non-condensing
Shock rating
Continuous shock
per EN60068-2-27
3)
50g/6ms
50g/2ms
Vibration
per EN 60068-2-6
3)
12g, 10…2000Hz
Degree of protection per
IEC60529
IP67
(when attached)
10.3 Supply voltage (external)
Voltage, stabilized
4)
10…30VDC
Ripple ≤0.5V
PP
Current draw (at24VDC) ≤150mA
Inrush current ≤3A/0.5ms
Reverse polarity protection
5)
Up to 36V
Overvoltage protection Up to 36V
Dielectric strength
(GND to housing)
500VDC
10.4 Output
BTL6-A… Output voltage
Load current
0…10V
Max. 5mA
BTL6-C… Output current
Load resistance
0.1…20mA
≤500ohms
BTL6-E… Output current
Load resistance
4…20mA
≤500ohms
BTL6-G… Output voltage
Load current
−10…10V
Max.5mA
Short circuit resistance Signal cable to 36 V
Signal cable to GND
10.5 Input
Programming inputs La/Lb 10…30VDC
High-active
Overvoltage protection Up to 36V
10.6 Dimensions, weights
Housing height 20.8mm
Nominal length 50…4572mm
Weight (depends on length) Approx.1kg/m
Housing material Aluminum
1)
Nominal length500mm, magnet in the middle of the measuring range
2)
For
: Use in enclosed spaces and up to a height of 2000 m above sea
level.
3)
Individual specifications as per Balluff factory standard, resonances
excluded
4)
For
: The transducer must be externally connected via a limited-
energy circuit as defined in UL 61010-1, a low-power source
as defined in UL 60950-1, or a class 2 power supply as defined
in UL 1310 or UL 1585.
5)
A prerequisite is that no current can flow between GND and 0 V in the
event of polarity reversal.
10
Technical data
BTL6-A/C/E/G500-M _ _ _ _ -PF-S115
Micropulse Transducer in a Flat Profile Housing

Balluff BTL6-A/C/E/G500-M Series Specifications

General

Brand	Balluff
Model	BTL6-A/C/E/G500-M Series
Category	Transducer
Language	English
