Balluff BTL6-A/C/E/G500-M Series - Notes to the user; Validity; Symbols and conventions; Scope of delivery

www.balluff.com 5english
1.1 Validity
This guide describes the construction, function and setup
options for the BTL6 Micropulse Transducer with analog
interface. It applies to types
BTL6-A/C/E/G500-M____-PF-S115 (see Ordering
code on page20).
The guide is intended for qualified technical personnel.
Read this guide before installing and operating the trans-
ducer.
1.2 Symbols and conventions
Individual handling instructions are indicated by a
preceding triangle.
► Action instruction 1
Action sequences are numbered consecutively:
1. Action instruction 1
2. Action instruction 2
Note, tip
This symbol indicates general notes.
a
b
These symbols indicate the programming
inputs.
Symbols of this type indicate the LED display.
1.3 Scope of delivery
– BTL6 transducer
– Mounting clamps with insulating sleeves and screws
– Condensed guide
The magnets are available in various models
and must be ordered separately.
1.4 Approvals and markings
UL approval
File no.
E227256
US Patent 5923164
The US patent was awarded in connection with this
product.
The CE Mark verifies that our products
meet the requirements of the current
EMC Directive.
The transducer meets the requirements of the following
product standard:
– EN 61326-2-3 (noise immunity and emission)
Emission tests:
– RF emission
EN 55011
Noise immunity tests:
– Static electricity (ESD)
EN 61000-4-2
Severity level 3
– Electromagnetic fields (RFI)
EN 61000-4-3
Severity level 3
– Electrical fast transients (burst)
EN 61000-4-4
Severity level 3
– Surge
EN 61000-4-5
Severity level 2
– Conducted interference induced
by high-frequency fields
EN 61000-4-6
Severity level 3
– Magnetic fields
EN 61000-4-8
Severity level 4
More detailed information on the guidelines,
approvals, and standards is included in the
declaration of conformity.
1
Notes to the user
BTL6-A/C/E/G500-M _ _ _ _ -PF-S115
Micropulse Transducer in a Flat Profile Housing
