www.balluff.com 5english
1.1 Symbols and conventions
Instructions are indicated by a preceding triangle. The
result of an action is indicated by an arrow.
► Instruction 1
⇒ Action result
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Buttons are written in small caps, e.g.
CanCel.
Menu commands are linked with a greater than symbol,
e.g. “Settings > Options” represents the menu command
“Options” from the “Settings” menu.
Note, tip
This symbol indicates general notes.
1.2 Explanation of the warnings
Always observe the warnings in these instructions and the
measures described to avoid hazards.
The warnings used here contain various signal words and
are structured as follows:
SIGNAL WORD
Hazard type and source
Consequences if not complied with
► Measures to avoid hazards
The signal word means:
DANGER
The general warning symbol in conjunction with the
signal word DANGER identifies a hazard which, if not
avoided, will certainly result in death or serious injury.
1.3 Abbreviations
CIP Common Industrial Protocol
EDS Electronic Data Sheet
ODVA Open DeviceNet Vendor Association
FMM Flexible Magnet Mode
1.4 Registered trademarks
CIP, CIP Safety, CIP Motion, CIP Sync, DeviceNet,
CompoNet, ControlNet, EtherNet/IP and ODVA are
registered trademarks of ODVA.
RSLogix is a registered trademark of Rockwell Automation,
Inc.
All other mentioned brands are the property of the
respective rightful owner.
1
Notes to the user
BTL7-V50D-…
Configuration Manual
