Appendix (continued)
9.3 Attributes of the device configuration object (class 100 (0x64))
Attribute Designation Access
1)
M
1)
Type Default
value
Comments
1 Synchronous
Mode
W NV BOOL FALSE Operating mode:
– FALSE: Asynchronously
– TRUE: Synchronously
2 Synchronous
Period
W NV UINT – Desired cycle time of the SYNC0 signal
in ns
3 Synchronous
Shifttime
W NV UINT 0 Bringing forward of the measurement
time in ns
4 Synchronous
Offset
W NV UINT 0 Displacement of the SYNC0 time in ns
5 Asynchronus
Period
W NV – Cycle time in asynchronous operation
6 Number of
Magnets
W NV SINT 1 The number of magnets:
– 0: Flexible Magnet Mode
– 1…16: Number
7 Measurement
Status
R NV SINT – Status of measurement detection:
– Bit 0…4: Number of detected magnets
(00000:0magnets; 00001:1magnet;
00010:2magnets; 00011:3magnets;
…; 10000:16magnets)
– Bit 5…6: Measurement mode
(00:Asynchronous; 10:Synchronous)
– Bit 7: Measurement error, if set
8 Service Function 1 W INT – Service function: Not for users
9 Service Function 2 W INT – Service function: Not for users
10 Service Function 3 W INT – Service function: Not for users
11 Actual
Temperature
R INT – Current temperature of electronics
12 Session Maximum
Temperature
R INT Maximum temperature since the last
reset
13 Session Minimum
Temperature
R INT Minimum temperature since the last
reset
14 Lifetime Maximum
Temperature
R INT Service life: Maximum temperature
15 Lifetime Minimum
Temperature
R INT Service life: Minimum temperature
16 FMM Timeout W NV SINT Error time in FMM operation
17 Averaging Filter W NV SINT Measurements for averaging
30 Type R C STRING Type string
31 Serial Number R C STRING Serial number
32 Serial Number U32 R C UINT Serial number in digits
33 Firmware Version R C STRING Firmware version installed
34 Hardware Version R C STRING Hardware version installed
1) C= Constant (constant value), M= Memory, NV= Non-Volatile
(remanent saving), R= Read, V= Volatile (no saving), W= Write
Tab. 9-3: Attributes of the device configuration object
BTL7-V50D-…
Configuration Manual
