B&C CL 7685 - Set A;B; Alarm (Relay C)

B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 10 –
5) SET A/B |
|
* Selectable actions: |
ON-OFF |
PFM - Pulse frequency proportional |
PWM - Pulse width proportional |
* Action: ON-OFF | SET B
Value: 0/2.000 - 0/20.00 PPM (as scale selected) | 0 PPM
Hysteresis: 0/0.200-0/2.00 PPM (as scale selected) | 0.2 PPM
Activation delay: 0/99.9 " | 0.0"
* Function: HI/LO (Max/min) | LO
|
* Action: PFM | SET A
Value: 0/20.00 PPM (as scale selected) | 0 PPM
Proportional band: 0/0.200 - 0/2.00 PPM | 0.2 PPM
(as scale selected) |
Pulse max. Frequency: 0/120 pulse/minute | 100 p/m
Pulse width: | 0.1"
* Function: HI/LO (Max/min) | LO
|
* Action: PWM |
Value: 0/0.200 - 0/20.00 PPM (as scale selected) | 0 PPM
Proportional band: 0/0.200 - 0/2.00 PPM | 0.2 PPM
(as scale selected) |
Pulse width: 0/99.9" | 20.0"
Min. pulse width: | 0.3"
* Function: HI/LO (Max/min) | LO
Relay Contacts: SPDT 220 V 5 A Resistive load |
6) ALARM (RELAY C) |
|
High value: 0/2.000 - 0/20.00 PPM (as scale selected) | 20.00 PPM
Low value: 0/2.000 - 0/20.00 PPM (as scale selected) | 0.00 PPM
Delay: 0/99.9 " | 0.0"
* Alarm on max. SA: ON/OFF | OFF
* Max. time SA: 0/60 minutes | 60 min
* Alarm on max. SB: ON/OFF | OFF
* Max. time SB: 0/60 minutes | 60 min
* Contact type: ACT/DEA | ACT
Relay Contact: SPST 220 V 5 A Resistive load |
