B&C Electronics CL 7685
Operator’s Manual - Rev. C - 05/05
- 11 –
7) CLEANING FUNCTION (RELAY D) |
|
* Action: Disable/Manual Clean/Auto+Manual Clean | Disable
|
Auto Clean: |
Time repetition: 0.1/24.0 h | 24.0 h
* Cleaning time: 0.5/60.0" | 15.0"
* Hold time: 0.1'/20.0' | 3.0'
|
Relay contacts: SPST |
8) ANALOG OUTPUT Nr. 1 |
|
* Current range: 0-20/4-20 mA | 0/20 mA
* Point 1 corresponding to 0 mA or 4 mA |
RANGE 20.00 PPM: 0.00/20.00 | 0.00 PPM
RANGE 2.000 PPM: 0.000/2.000 | 0.000 PPM
TEMPERATURE: 0.0°C/50.0°C (Option 091.3711) | 0.0 °C
* Point 2 corresponding to 20 mA |
RANGE 20.00 PPM: 0.00/20.00 | 20.0 PPM
RANGE 2.000 PPM: 0.000/2.000 | 2.000 PPM
TEMPERATURE: 0.0°C/50.0°C (Option 091.3711) | 50.0 °C
Response time: 10 s for 98 % |
Isolation: 250 Vca |
Rmax: 600 Ω |
9) ANALOG OUTPUT N°2 (only for Option 091.3711) |
|
* Current range: 0-20/4-20 mA | 0/20 mA
* Point 1 corresponding to 0 mA or 4 mA |
RANGE 20.00 PPM: 0.00/20.00 | 0.00 PPM
RANGE 2.000 PPM: 0.000/2.000 | 0.000 PPM
TEMPERATURE: 0.0 °C/50.0 °C | 0.0 °C
* Point 2 corresponding to 20 mA |
RANGE 20.00 PPM: 0.00/20.00 | 20.00 PPM
RANGE 2.000 PPM: 0.000/2.000 | 2.000 PPM
TEMPERATURE: 0.0 °C/50.0 °C | 50.0 °C
Response time: 10 s for 98 % |
Isolation: 250 Vca |
Rmax: 600 Ω |
