Bandit
115Copyright 12/17
MODEL 20XP
Tank assemblies vary with options. Specify all options when ordering.NOTICE
LOCATION PART NUMBER DESCRIPTION
FUEL & HYDRAULIC TANK COMPONENTS
1. 937-2001-63 30 Gallon Rectangle Hydraulic Tank Assembly - In Tank Filter)
2. 900-3922-60 Magnetic Drain Plug
3. a. 900-4912-40 Padlock With Short Shackle for Tank With Locking Cap
b. 900-4917-21 Key for Padlock (Not Shown)
4. a. 900-3941-31 Fuel (Diesel) Locking Fill Cap - Green
b. 900-3941-30 Hydraulic Locking Fill Cap - Black
c. 900-3935-06 Keeper for Fuel & Hydraulic Locking Fill Cap (Not Shown)
5. 900-3975-03 Sight Gauge
6. a. 900-3950-56 In Tank Filter Assembly
b. 900-3950-58 In Tank Filter
7. 900-7900-14 Rubber Mounting Pad
8. 937-200029 60 Gallon Rectangle Fuel Tank Assembly
9. a. 900-2903-95 Rochester Sight Gauge for 40 Gallon Rectangle Fuel Tank (Start 12/05)
b. 900-3923-28 Rochester Sight Gauge for 60 Gallon Rectangle Fuel Tank
c. 900-2903-55 Face for Sight Gauge Only
10. a. 900-3926-84 Suction Drop Pipe Ass’y Without Hose Barb (1/2” NPTF Male x 3/8” NPTF Female)
b. 900-3926-83 3/8” NPTF To 1/2” Hose Barb
c. 900-3926-82 3/8” NPTF To 3/8” Hose Barb
d. 900-3931-53 3/8” NPTF To 5/16” Hose Barb
11. a. 900-3909-00 Return Drop Pipe Ass’y Without Hose Barb (3/8” NPTF Male x 1/4” NPTF Female)
b. 900-3925-48 1/4” NPTF To 3/8” Hose Barb
c. 900-3909-01 1/4” NPTF To 5/16” Hose Barb
d. 900-3909-02 1/4” NPTF To 1/4” Hose Barb
e. 900-3943-22 3/16” NPTF To 3/16” Hose Barb
f. 900-3943-21 1/4” NPTF To 3/16” NPTF Bushing
12. a. 937-300088 Combination Tank Mount - 40 or 60 Gal. Fuel Tank & 24 or 30 Gal. Hyd. Tank
b. 900-0104-95 Rubber Tank Pad (Not Shown)
c. 900-7900-35 Tank Cushion Material (Not Shown)
13. 937-200074 50 Gallon Rectangle Hydraulic Tank Assembly
14. a. 900-3932-95 Filter Head Assembly (Includes Filter)
b. 900-3931-34 Filter Only
15. 900-3901-73 Filter Gauge
16. 900-3923-28 Rochester Sight Gauge for 50 Gallon Fuel Tank
17. 937-200073 50 Gallon Rectangle Fuel Tank Assembly
18. a. 937-2002-64 Tank Tray - 50 Gallon Rectangle Tank
b. 900-0104-95 Rubber Tank Pad (Not Shown)
c. 900-7900-35 Tank Cushion Material (Not Shown)
19. 980-0506-85 Optional Fill Cap Lock Assembly for Steel Tank With 900-3917-71 Fill Cap
20. 900-3917-71 Optional Fill Cap Only No Dipstick (Steel Tank)
