Bandit 20XP - Infeed Hopper Components

Bandit
91Copyright 12/17
MODEL 20XP INFEED HOPPER COMPONENTS
LOCATION PART NUMBER DESCRIPTION
Nuts, bolts, washers, and all other components can be ordered by physical description.
NOTICE
1. 900-2927-85 Red LED Light
2. 937-2004-33 Light Mount
3. 937-3016-09 Light Mount Holder
4. 900-2923-53 LED Taillight
5. 914-2001-15 Right Side Taillight
6. 914-2001-14 Left Side Taillight
7. 980-2002-82 Heavy Duty Taillight Cover
8. 905-8000-07 Fuel Saver
9. 980-300290 License Plate Mount
10. 900-2927-84 License Plate Light
11. 900-3907-71 Bottom Feedwheel Hydraulic Motor
12. 937-1004-34 Coupler
13. 900-4905-56 Tapered Pin for Coupler
14. 937-1004-97 Rubber Coupler Guard
15. 937-1009-94 Coupler Guard Mount
16. 955-300103 Torque Arm
17. a. 937-3014-09 Torque Arm Stop
b. 937-300316 Torque Arm Cushion Mount
18. 937-900009 Torque Arm Stop Cushion
19. a. 900-1904-07 Feedwheel Bearing
b. 900-4900-19 Feedwheel Bearing Bolt (Not Shown)
20. 955-1002-14 Bottom Feedwheel Bearing Backer Plate
21. a. 981-300031 Bottom Mount for Easy Climb System
b. 900-4905-79 Clevis Pin (Not Shown)
c. 900-4905-80 Cotter Pin for Clevis Pin (Not Shown)
d. 900-4906-90 Flat Washer (Not Shown)
22. 900-4905-18 Yoke Spring
23. a. 981-300030 Top Mount for Easy Climb System
b. 900-4905-14 Clevis Pin (Not Shown)
c. 900-4905-19 Hair Pin for Clevis Pin (Not Shown)
24. 937-300285 Yoke Slide - 2” x 2” x 24”
25. 900-1901-37 Sprocket for Top Feedwheel
26. a. 900-1901-39 Top Feedwheel Drive Chain (80-2)
b. 900-1905-62 Master Link
c. 900-1905-61 Half Link
27. 900-1900-08 Tapered Bushing
28. 937-2002-46 Top Drive Chain Guard
29. 900-1901-36 Top Feedwheel Motor Sprocket Bushing
30. 900-1901-35 Sprocket for Top Hydraulic Motor
31. 955-2001-68 Bolt on Motor Mount Assembly
32. 900-3906-29 Top Feedwheel Hydraulic Motor
33. 955-2002-24 Top Drive Motor Mount
34. 937-0502-01 Top Yoke Lifting Assembly
35. a. 900-3925-07 Yoke Lift Cylinder-Welded
b. 904-0007-14 Pin For Welded Cylinder (Not Shown)
c. 900-4913-23 Rubber Washer - Top Of Cylinder (Not Shown)
36. 955-2002-11 Yoke Lock Pin
37. 937-0501-89 Top Yoke Assembly
38. a. 937-0501-10 Top Feedwheel Assembly
b. 937-1007-63 Top Feedwheel Tooth
c. 937-1007-41 Top Feedwheel Shaft
39. 937-2004-01 Feedwheel Slide Box Assembly
40. a. 937-0501-09 Bottom Feedwheel Assembly
b. 937-1007-50 Bottom Feedwheel Tooth
c. 937-0501-57 Bottom Feedwheel Shaft & Coupler Assembly
41. 900-4901-83 Spring Loaded Pin
42. a. 937-1009-07 Trap Door Assembly
b. 981-1000-60 Hinge For Trap Door
43. 937-1015-19 Infeed Hopper Assembly
