Bandit
95Copyright 12/17
MODEL 20XP
LOCATION PART NUMBER DESCRIPTION
** Components vary with engine options order by physical description or machine S/N.
Nuts, bolts, washers, and all other components can be ordered by physical description.
NOTICE
CHIPPER COMPONENTS
1. See Page 102 Anvil
2. 955-1003-94 Drum Lock Pin
3. 911-1001-88 Vent Cover
4. 920-300066 Base Slot Cover
5. a. 937-300007 Air Vent Cover - Steel
b. 937-300008 Air Vent Cover - Aluminum
c. 937-100001 Air Vent Cover Kit - Steel (Includes Two Pieces of 4a, 5, & 6)
d. 937-100000 Air Vent Cover Kit - Aluminum (Includes Two Pieces of 4b, 5, & 6)
e. 900-4908-33 Spring for Vent Cover (Not Shown)
6. 900-4908-29 Plastic Knob for Vent Cover
7. a. 900-1906-51 Chipper Drum Bearing
b. 900-4910-41 Chipper Drum Bearing Bolt (3/4”-10NC x 5” Hex Head) (Left Side Only)
c. 900-4910-34 Chipper Drum Bearing Bolt (3/4”-10NC x 4 1/2” Hex Head) (Right Side Only)
d. 900-4901-47 Washer for Chipper Drum Bearing (3/4” Mill Carb)
e. 900-4910-19 Chipper Drum Bearing Jam Nut (3/4”-10NC Hex Jam Nut) (Left Side Only)
f. 900-4901-23 Chipper Drum Bearing Nut (3/4”-10NC Hex Nut) (Right Side Only)
8. 937-3012-85 Drum Shaft Bearing Cover
9. 920-200033 Bearing Cover
10. 900-3921-02 Chipper Bearing Grease Line
11. 900-1911-83 Taper Lock Bushing
12. 920-300064 Drum Shaft Key
13. 920-3008-44 Drum Head Shaft
14. 920-1000-60 Drum Head
15. See Page 96 Chipper Knife
16. 920-2001-63 Drum Housing Door Assembly (Includes 18 & 19)
17. 920-300310 Drum Housing Door
18. 900-4905-37 Hood Pin With Attaching Chain
19. a. 900-4902-20 Padlock For Hood Pin (Not Shown)
b. 900- 4917-21 Key For Padlock (Not Shown)
20. a. 909-1000-01 Engine Disable Plug Kit (Includes Plug, Wiring, & Mounts)
b. 980-100083 6-Prong Male Plug With Wire Loop & Crimp Sleeves
21. 937-1008-47 Clean Out Frame
22. a. 900-4908-27 Discharge Spring Lock
b. 900-7900-96 Rubber Cap (Not Shown)
23. 937-1005-63 Transition Flange
24. 980-0122-18 Bottom Swivel Ring For Hydraulic Swivel Discharge
25. 937-1014-42 Transition Assembly
26. 937-2002-47 Optional Chip Breaker Assembly
27. 937-300189 Adjustable Cover - Engine PTO Sheave
28. ** Chipper Belts
29. ** Engine Sheave Bushing
30. ** Engine Sheave
31. ** Chipper Sheave Bushing
32. ** Chipper Sheave
33. a. 920-200051 Beltshield Assembly - 1500 Belts
b. 937-2004-35 Beltshield Assembly - 1700 Belts
34. 900-9910-28 Manual Holder - 8” x 11” x 2”
To Next Page
