Bandit 20XP - Optional Components

Bandit
119Copyright 12/17
MODEL 20XP
LOCATION PART NUMBER DESCRIPTION
OPTIONAL COMPONENTS
MODEL 75 LOADER
1. a. 914-1017-14 Pivot Pin for Swing Brake - 7 5/8”
b. 955-1010-72 Pivot Pin Keeper - Weld On
2. 900-4900-80 Nylon Lock Nut for Main Boom Pin
3. 955-1016-01 Clamp for Jib Boom Pipe
4. 914-0502-97 Jib Boom Assembly
5. 914-1018-24 Pipe for Jib Boom
6. a. 914-1017-13 Cylinder Pin - 5 1/2”
b. 955-1010-72 Cylinder Pin Keeper - Weld On
7. 900-1905-35 Split Steel Bushing - 2 1/2” OD x 2” ID x 1 1/2”
8. 900-3924-07 Hydraulic Cylinder - 3” x 24”
9. 955-3006-85 Loader Pin Lock Nut - 1 3/4”
10. 960-0011-67 Bushing for Pivot Pin
11. a. 914-1017-16 Main to Jib Pivot Pin
b. 960-0013-47 End Cap for Pivot Pin - Weld On
12. 914-0502-96 Main Boom Assembly
13. 955-1010-62 Pipe Clamp for Main Boom
14. 914-1018-22 Pipe for Main Boom - SCH 40 x 29”
15. 914-1018-23 Pipe for Main Boom - SCH 40 x 54”
16. 900-3924-06 Hydraulic Cylinder - 3” x 24” with a 4” Stop
17. a. 914-1017-15 Cylinder Pin - 7”
b. 955-1010-72 Pivot Pin Keeper - Weld On
18. 916-0006-21 Pipe Clamp for Main Boom
19. 900-9900-35 Split Steel Bushing - 2 1/2” x 2” x 2 1/2”
20. a. 914-1016-98 Cylinder Pin - 9”
b. 955-1010-72 Pivot Pin Keeper - Weld On
21. 914-0503-10 Pedestal Assembly
22. a. 914-1017-17 Pivot Pin - 14 5/8”
b. 960-0013-47 End Cap for Pivot Pin - Weld On
23. 900-3903-01 Hydraulic Cylinder - 3” x 16”
24. 914-1017-86 Pad Support
25. 914-1016-40 Pivot Pin
26. 900-4902-35 Pin - 1” 4 1/4”
