MODEL 20XP CONVEYOR COMPONENTS
LOCATION PART NUMBER DESCRIPTION
Nuts, bolts, washers, and all other components can be ordered by physical description.NOTICE
1. 900-3907-71 Hydraulic Conveyor / Bottom Feedwheel Motor
2. 937-1004-34 Feedwheel Coupler
3. 900-4905-56 Taper Pin for Feedwheel Coupler
4. 937-1004-97 Rubber Coupler Guard
5. 937-1009-94 Coupler Guard Mount
6. 955-300103 Torque Arm
7. a. 937-3014-09 Torque Arm Stop
b. 937-300316 Torque Arm Cushion Mount
8. 937-900009 Torque Arm Stop Cushion
9. 900-1900-34 Conveyor Bearing
10. 937-2003-70 Conveyor Drive Wheel
11. 900-1906-33 Idler Bearing for Conveyor
12. 249-2000-08 Conveyor Idler Assembly
13. 249-2000-28 Rear Bumper
14. 937-1014-83 Conveyor Infeed Assembly
15. a. 900-1904-07 Feedwheel Bearing
b. 900-4900-19 Feedwheel Bearing Bolt
16. 955-1002-14 Bottom Feedwheel Bearing Backer Plate
17. a. 981-300031 Bottom Mount for Easy Climb System
b. 900-4905-79 Clevis Pin (Not Shown)
c. 900-4905-80 Cotter Pin for Clevis Pin (Not Shown)
d. 900-4906-90 Flat Washer (Not Shown)
18. 900-4905-18 Yoke Spring
19. a. 981-300030 Top Mount for Easy Climb System
b. 900-4905-14 Clevis Pin (Not Shown)
c. 900-4905-19 Hair Pin for Clevis Pin (Not Shown)
20. 987-300285 Yoke Slide - 2” x 2” x 24”
21. a. 900-1901-39 Top Feedwheel Drive Chain (80-2)
b. 900-1905-62 Master Link
c. 900-1905-61 Half Link
22. 900-1901-37 Sprocket for Top Feedwheel
23. 900-1900-08 Bushing for Top Feedwheel Sprocket
24. 937-2002-46 Top Feedwheel Chain Guard
25. 900-1901-36 Top Feedwheel Motor Sprocket Bushing
26. 900-1901-35 Sprocket for Top Feedwheel Motor
27. 900-3906-29 Top Feedwheel Hydraulic Motor
28. 955-2001-68 Bolt-On Motor Mount Assembly
29. 955-2002-24 Top Feedwheel Hydraulic Motor Mount
30. 937-0502-01 Yoke Lift Assembly
31. a. 900-3925-07 Yoke Lift Cylinder - Welded
b. 904-0007-14 Pin for Welded Cylinder (Not Shown)
c. 900-4913-23 Rubber Washer - Top of Cylinder (Not Shown)
32. 955-2002-11 Yoke Lock Pin
33. 937-0501-89 Top Yoke Assembly
34. a. 937-1007-62 Top Feedwheel Assembly
b. 937-1007-63 Top Feedwheel Tooth
c. 937-1007-41 Top Feedwheel Shaft
35. 937-2004-01 Feedwheel Slide Box Assembly
36. a. 937-0501-09 Bottom Feedwheel
b. 937-1007-63 Bottom Feedwheel Tooth
c. 937-1007-41 Bottom Feedwheel Shaft
37. 900-4901-83 Trap Door Lock Pin
38. a. 937-2004-65 Trap Door
b. 937-1015-31 Trap Door Assembly (Includes 36)
39. 955-0501-47 Conveyor Chain Link (24 Links Required)
40. 900-3925-07 Folding Conveyor Cylinder
41. 937-2001-81 Folding Conveyor Pin
