Bandit
73Copyright 12/17
MODEL 20XP
HYDRAULICS
D-03 6/17
LOCKOUT ALL ENERGY SOURCES
BEFORE SERVICING OR REMOVING
GUARDS OR HOODS!
1. Shut o engine/motor. Key in possession.
2. Disengage pto/clutch.
3. Wait for cutter disc/drum to come to a
COMPLETE STOP (takes at least several
minutes).
4. Install disc/drum lock pin.
5. Loader arm (if equipped) securely on ground
and hydraulic pressure released.
6. Unplug engine disable
plug-in.
7. Remove padlock from hood pin.
8. Press down and hold hood spring lock pin (on
disc chippers).
9. Retract hood pin.
DO NOT RESTART UNTIL ALL GUARDS
AND HOODS ARE SECURELY AND
PROPERLY INSTALLED.
DANGER
!
W-01 10/17
WARNING
!
• Pressured oil easily punctures skin causing
injury, gangrene or death.
• Seek immediate medical care.
• Do not use nger or skin to check for leaks.
• Remove hydraulic pressure or load before
loosening ttings.
• Hydraulic components and oil may be hot.
Allow su cient time to cool.
• Avoid burns from uid. Hot uid under
pressure can cause severe burns.
DO NOT GO NEAR LEAKS!
HYDRAULICS
