MODEL 20XP ELECTRICAL
TYPICAL ELECTRICAL WIRING DIAGRAMS
6 Wire Main Cable Color Code
Red R (Brakes & Breakaway Switch)
White W (Ground)
Green G (Right Turn)
Yellow Y (Left Turn)
Brown BR (Running Lights)
Black BL (Power to Breakaway Switch)
WIRING FOR STANDARD 6 PRONG PLUG
AND 6 WIRE MAIN CABLE
JUNCTION BOX
WIRES SPLICED
TOGETHER WHITE
WIRES GROUNDED
J
JUNCTION BOX
Running Lights
(BR)
Right Turn
(G)
Left Turn
(Y)
Ground
(W)
Brakes
(R)
BR
BR
G
G
BR
BRBRRRBRBR
BRBRRRBRBR
W W
W
W
W
W
W
W
W
W
W
W
BR
LICENSE PLATE
LIGHT
ELECTRIC
BRAKES
ELECTRIC
BRAKES
ELECTRIC
BRAKES
ELECTRIC
BRAKES
RED MARKER
LIGHT
RED MARKER
LIGHT
AMBER MARKER
LIGHT
AMBER MARKER
LIGHT
3 LIGHT
MARKER BAR
(IF APPLICABLE)
TAIL LIGHT
TAIL LIGHT
J
RIGHT TURN - GREEN WIRE
LEFT TURN - YELLOW WIRE
ELECTRIC BRAKES - RED WIRE
GROUND - WHITE WIRE
RUNNING LIGHTS - BROWN WIRE
BREAKAWAY
SWITCH
POWER TO BREAKAWAY - BLACK WIRE
S
A
TM GD
LT
RT
