TYPICAL HYDRAULIC RELIEF PRESSURE SETTINGS
TYPICAL HYDRAULIC FLOWS AND RPM SETTINGS
(Approximate, For Reference Only, Engine At Full RPM)
After the initial start-up of the machine and after any replacement of hydraulic components, that ttings
and hoses should be re-checked for leaks and clearances.
DO NOT UNDER ANY CIRCUMSTANCES OVER-SET THESE RELIEF PRESSURES, BECAUSE IT WILL
CAUSE DAMAGE TO COMPONENT PARTS AS WELL AS HYDRAULIC PARTS.
These typical hydraulic ows and relief pressure settings are with the engine at full RPM. All settings are
subject to change!
NOTICE
NOTICE
CAUTION
!
HYDRAULICS
HYDRAULICS
Equipment
Model
20XP 20XP Track
Pump
GPM (LPM)
28
(106)
Feed
28 (106)
Track
24 (91)
Top Feedwheel
GPM (LPM)
12
(45.4)
12
(45.4)
Bottom Feedwheel
GPM (LPM)
16
(60.5)
16
(60.5)
Feedwheel
RPM
Top
28
Bottom
41
Top
28
Bottom
41
Main Relief
PSI (bar)
Top
2300 (159)
Bottom
2600 (179)
Top
2300 (159)
Bottom
2600 (179)
Yoke Relief
PSI (bar)
Up
1150 (79)
Down
1850 (128)
Up
1150 (79)
Down
1850 (128)
Discharge Rotate
PSI (bar)
1000
(69)
2000
(138)
Discharge Flipper
PSI (bar)
1000
(69)
2200
(152)
Stabilizers
PSI (bar)
1000
(69)
N/A
Tongue Jack
PSI (bar)
2200
(152)
N/A
2 Speed
PSI (bar)
N/A
750
(52)
Equipment
Model
75 Loader
Jib In/Out
PSI (bar)
2200
(151)
Swing Left/Right
PSI (bar)
1800
(124)
Grapple Rotate
PSI (bar)
2200
(151)
Main Boom
PSI (bar)
Up
2600 (179)
Down
1000 (69)
Grapple
PSI (bar)
2200
(151)
