TECHNICAL SPECIFICATION
GENERAL
Frequency range
65MHz-108MHz (Only commercial FM radio reception)
VHF:136MHz-174MHz (Rx/Tx)
UHF:400MHz-470MHz (Rx/Tx)
Memory channels Up to 99 channels
Frequency stability 2.5ppm
Frequency step 5kHz/6.25kHz/10kHz/12.5kHz/20kHz/25kHz
Antenna impedance 50Ω
Operating temperature -20°C to +60°C
Supply voltage Rechargeable Lithium-Ion 7.4V/1800mAh
Mode of operation Simplex or semi-duplex
Duty cycle 03/03/54min. (Rx / Tx / Standby)
TRANSMITTER
RF power 5W/1W
Type of modulation F3E
Maximum deviation ≤±5kHz / ≤±2.5kHz (W/N)
Spurious emissions ≤7.5uW
Ajacent channel power ≤-65dB / ≤-60dB
RECEIVER
Receiver sensitivity 0.2µV (at 12dB SINAD)
Intermodulation 65dB
Audio output 1W
Ajacent channel selectivity 65dB
Spurious response 65dB
Receiving current <380mA
Note:
- All specifications shown are subject to change without notice.
