Barco ClickShare CSE-800 Installation Guides

R5900049 /07 ClickShare CSE-800 27
Contact your local sales representative for the correct regional variant to be used in your country.
2.2 CSE-800 specifications
Base Unit
Dimensions (HxWxD) 46.2mm x 282.3mm x 206.5mm (excl. antennas) / 1.8" x 11.1" x 8.1"
146.4mm x 282.3mm x 206.5mm (incl. antennas) / 5.8"x 11.1" x 8.1"
Power supply Standard 110/220 V AC plug
Power consumption Normal operation:
90W under full usage
52W under normal usage (connect 2 HDMI outputs, connect 1 HDMI input,
share with 4 people)
ECO mode: 30W
Networked standby mode: < 1W
Deep standby mode: < 0.5W
Weight 2.2kg / 4.85lbs
Operating system Windows 7/8/8.1/10 32 & 64 bit
macOS 10.10/10.11/10.12/10.13/10.14 (Mojave)
Android v5 & v6 & v7 & v8 & 8.1 (ClickShare app)
iOS 8, 9, 10, 11& 12 (ClickShare app)
Video outputs 2x HDMI
Video inputs 2x HDMI
Output resolution 4K DCI (4096x2160) @ 60Hz
AirPlay Support iOS mirroring (AirPlay) from iOS 9.0 up to iOS 12 / Mac OS 10.14
Google Cast Support Android 8.1 Oreo
Input resolutions 4K DCI (4096x2160) @ 60Hz
Frame rate Using inputs:
Up to 60fps with one input @ 4K
Up to 30fps with two inputs @ 4K
Using the ClickShare Button or Apps:
Up to 30 fps
Noise Level Max. 25dBA @ 0-30°C
Max. 30dBA @ 30-40°C
Number of sources
simultaneous on screen
8 (4 per screen)
Number of simultaneous
connections
64
iPad, iPhone and Android
compatibility
Sharing of documents, browser, camera for both Android and iOS devices
via ClickShare app
Extended desktop Available (depending on your operating system). May require ClickShare
Extension Pack.
Authentication protocol WPA2-PSK in stand alone mode
WPA2-PSK or IEEE 802.1X using the ClickShare Button in network
integration mode
